Are you tired of the inefficiencies and inaccuracies of traditional leather - cutting methods? Look no further than our Automatic Dieless CNC Pu Leather Cutting Machine, a revolutionary solution designed to transform your leather - processing operations.
As a pu leather cutting machine, it is specifically engineered to handle PU leather with utmost precision. The use of advanced CNC (Computer Numerical Control) technology, which makes it a cnc pu cutting machine, is the key to its high - performance capabilities. This technology allows for the input of complex cutting patterns directly into the machine's control system. Once the design is uploaded, the machine can execute the cutting tasks with unrivaled accuracy, down to the smallest detail.
Cutting effect of Automatic Dieless Cnc Pu Leather Cutting Machine:
Model | RZCRT5-2516EF |
Effective Working Area | (L)2500mm*(W)1600mm |
Machine Dimension | (L)3530mm*(W)2210mm |
Cutting Speed | 100-1200mm/s |
Cutting Thickness | 0.1-50mm |
Processing Material | PU materials, synthetic materials, artificial leather, counter, mash fabric, footwear trimmings, microfiber leather, etc. |
Nesting | Automatic nesting, improve material utilization |
Hold Method | Vacuum absorption |
Machine Language | HP-GL / GP-GL |
Interface | Ethernet port |
Accuracy | Less than 0.1mm |
Available Tools | Pneumatic Oscillating Tool, Pen and Holes Punching Tool |
Vibration Knife | Electronic, driven by Swiss high frequency motor |
Cutting Features | 1. Cutting by blade, no laser, no damage on leather. 2. Different types of cutting blades are available to work on various materials and meet different cutting requirements. |
Air Pump Power | 9KW |
Machine Working Voltage / Frequency | AC220V±22V / 50Hz±1Hz |
Air Pump Working Voltage / Frequency | AC380V±38V / 50Hz±1Hz |
feeding system
provides overall information intelligent cutting silutions
software with CAD common formats(plt)
avoid the risk of low efficiency and high fault-tolerant rato of manuak nesting
Dual cutting beams,double cuttiing effociency
A large number of cutting samples are often produced in a short period of time
Ruizhou Technology was founded in 1995. Its headquarters has a 27,000 square meter factory building and specializes in the production of intelligent CNC cutting machines and related CAD/CAM systems.
Ruizhou products are mainly used in soft material related fields such as footwear, clothing, automobiles, furniture, high-speed rail, luggage, aircraft interiors, lamps, leather, textiles, cardboard, plastic sheets, etc.
